SpeedyBee F7 V3 Flight Controller

$88.99
SKU:
RC-W1

SPEEDYBEE F7 V3 Flight Controller

The SpeedyBee F7 V3 Flight Controller is an F722 FC featuring a BMP280 barometer, OSD, 500MB Memory Blackbox, a built-in FC LiPo monitoring system, and many more features. Equipped with solder-free connectivity options, this FC is the perfect addition to your FPV build.


Features

  • 500MB Onboard Blackbox Flash memory
  • 8 Motor output perfect for X8 Cinelifters
  • 30.5 x 30.5mm Mounting Pattern
  • FC LiPo Monitoring System
  • Built-in Barometer
  • 4 LED Plugs
  • F722 FC
  • Buzzer

Specifications

  • Power Output:
  • 1) 10 groups of 5V output, three +5V pads and 1 BZ+ pad (used for Buzzer) on the front side, and 6 +5V output included in the connectors on the bottom side. The total current load is 2A.
  • 2) 2 groups of 9V output, one +9V pad on the front side and the other included in a connector on the bottom side. The total current load is 4A.
  • 3) Supported. Designed for receiver and GPS module even when the FC is powered through the USB port. Up to 1A current load Supported. Designed for 3.3V-input receivers. Up to 500mA current load.
  • WiFi Support, used for data transfer, e.g firmware flashing, and Blackbox analysis.
  • I2C: Supported. SDA & SCL pads on the front side. Used for magnetometer, sonar, etc.
  • Support Flight Controller Firmware: BetaFlight(Default), EMUFlight, INAV
  • ESC signal M1 - M4 on the bottom side and M5-M8 on the front side.
  • LED: Used for WS2812 LED controlled by Betaflight firmware.
  • UART: 5 sets (UART1, UART2, UART3, UART4, UART6)
  • DJI Air Unit plug: A full DJI Air Unit JST slot onboard
  • BLE Support, used for Flight Controller configuration
  • Buzzer: BZ+ and BZ- pad used for 5V Buzzer
  • Mounting: 30.5x30.5mm, 4mm hole size
  • Dimensions: 41(L) x 38(W) x 8.1(H)mm
  • OSD: BetaFlight OSD w/ AT7456E chip
  • BlackBox: 500MB onboard data flash
  • BetaFlight Camera Control Pad: Yes
  • ESC Telemetry: UART UART4 RX
  • Power input: 3S - 6S Lipo
  • Target: SPEEDYBEEF7V3
  • SmartPort: Supported
  • Baro: BMP280 (I2C)
  • MCU: STM32F722
  • Boot button: Yes
  • RSSI input: Yes
  • IMU: BMI270
  • USB: Type-C
  • Weight: 9G

Package Contents

  • 1x SpeedyBee F7 V3 Flight Controller
  • 1 4-Pin SH1.0 to SH1.0 Analog VTX Cable 60mm - Yellow and Blue
  • 1x 6-Pin SH1.0 GPS module Cable without connector - 100mm
  • 1 4-Pin SH1.0 to 3+ 2-Pin JST1.25 FPV Camera Cable - 30mm
  • 1 4-Pin SH1.0 to 3+ 2-Pin JST1.25 FPV Camera Cable - 60mm
  • 1 4-Pin SH1.0 to 4-Pin JST1.25 FPV Camera Cable - 60mm
  • 1x 6-Pin SH1.0 GPS module Cable with connector
  • 1 4-Pin SH1.0 Radio Receiver Cable - 100mm
  • 1x SH 1.0mm 8-Pin Cable -30mm
  • 5x M3 8mm Silicone Grommets
  • 1x DJI 6-Pin Cable - 80mm



Width:
10.00 (cm)
Height:
2.00 (cm)
Depth:
0.50 (cm)
Mounting:
30.5x30.5
CPU:
F7
