FLIGHT CONTROLLER Specifications

• Power Output:
• 1) 10 groups of 5V output, three +5V pads and 1 BZ+ pad (used for Buzzer) on the front side, and 6 +5V output included in the connectors on the bottom side. The total current load is 2A.
• 2) 2 groups of 9V output, one +9V pad on the front side and the other included in a connector on the bottom side. The total current load is 4A.
• 3) Supported. Designed for receiver and GPS module even when the FC is powered through the USB port. Up to 1A current load Supported. Designed for 3.3V-input receivers. Up to 500mA current load.
• WiFi Support, used for data transfer, e.g firmware flashing, and Blackbox analysis.
• I2C: Supported. SDA & SCL pads on the front side. Used for magnetometer, sonar, etc.
• Support Flight Controller Firmware: BetaFlight(Default), EMUFlight, INAV
• ESC signal M1 - M4 on the bottom side and M5-M8 on the front side.
• LED: Used for WS2812 LED controlled by Betaflight firmware.
• UART: 5 sets (UART1, UART2, UART3, UART4, UART6)
• DJI Air Unit plug: A full DJI Air Unit JST slot onboard
• BLE Support, used for Flight Controller configuration
• Buzzer: BZ+ and BZ- pad used for 5V Buzzer
• Mounting: 30.5x30.5mm, 4mm hole size
• Dimensions: 41(L) x 38(W) x 8.1(H)mm
• OSD: BetaFlight OSD w/ AT7456E chip
• BlackBox: 500MB onboard data flash
• BetaFlight Camera Control Pad: Yes
• ESC Telemetry: UART UART4 RX
• Power input: 3S - 6S Lipo
• Target: SPEEDYBEEF7V3
• SmartPort: Supported
• Baro: BMP280 (I2C)
• MCU: STM32F722
• Boot button: Yes
• RSSI input: Yes
• IMU: BMI270
• USB: Type-C
• Weight: 9G

ESC Specifications

• Current Sensor: Supported (Scale=490 Offset=0)
• Mounting: 30.5x0.5mm, 4mm hole size
• Dimension: 45.6(L)x40(W)x8.8mm(H)
• Firmware: SpeedyBee BL32 50A
• Weight: 19.2g with heat sink
• Continuous Current: 50Ax4
• Power input: 3S - 6S LiPo
• Burst Current: 55A(5S)
• Power output: VBAT
