• Lower latency than the competitor at an average of 22ms
• 6.8g Lightweight Mini VTX great for the 75x Quad
• Walksnail Avatar Mini 1S VTX Module
• Walksnail Avatar Nano Camera
• Built-in 8Gb Internal Storage
• 1080p Screen Resolution
• Switchable Aspect Ratio
• Walksnail IPEX Antenna
• 5.8GHz Frequency
• Onboard DVR
• Canvas Mode
• 170° FOV
• 3.1V-5V

AVATAR HD NANO CAMERA

• Resolution: 1080p 60FPS / 720P 120FPS / 720P 60FPS
• Aspect Ration: 16/9 and 4/3 Switchable
• Minimum Illumination: 0.001Lux
• Shutter Style: Rolling Shutter
• Dimensions: 14x14x17mm
• Cable Length: 90mm
• Image Sensor: 1/27"
• Field Of View: 170°
• Aperture: F 2.0
• Lens: 2.1mm
• Weight: 3.5g

AVATAR MINI 1S VTX MODULE

• Transition Power: FCC<25.5dBm / CE <14dBm / SRRC <20dBm / MIC <25dB
• I/O Interface: JST1.0 x 6 (Power In) to JST1.0 x 4 (USB)
• Operational Frequency: 5.725-5.850GHz
• Operating Temperature: -20° to 40°c
• Supported FC Firmware: Betaflight
• Video Resolution: 1080p / 720p
• Dimensions: 30x30x6.5mm
• Antenna Connector: IPEX
• Bitrate: 25mbps/50mbps
• Mounting: 25.5x25.5mm
• Latency: 22ms Average
• Internal Storage: 8GB
• Input Voltage: 3.1-5V
• OSD: Canvas Mode
• Weight: 6.8g
• Channels: 8

WALKSNAIL AVATAR VTX ANTENNA

• Radiation Efficiency: >= 98%
• Bandwidth: 5.6-5.9GHz
• Gain: 2dBi Average
• Polarization: LHCP
• Connector: IPEX
• Length: 90mm
• VSWR: <=1.4
• Weight: 1.5g
