Sequre Blueson A2 6S 65A ESC - AM32
Features
- High-quality ultra-high copper thickness PCB ensures the current carrying capacity while improving heat dissipation. Equipped with top-level MOSFET, it enhances flight performance and makes you enjoy the fun of flying in the air.
- Equipped with a high-speed 32-bit processor, it supports full-segment dynamic PWM variable refresh rate of 8KHz-128KHz, with more precise speed response and smoother throttle control.
- Supports 6S/8S wide range voltage input, allowing your aircraft to adapt to power batteries of different specifications, improving the versatility of the device.
- 30.5mm installation hole spacing is more suitable for large-sized load-type flight vehicles and is easy to install.
- The angled extended large-area pad design not only makes the motor circuit layout more refined, but also effectively simplifies the welding process.
Specifications
- Processor: AT32F421
- Firmware: AM32
- PWM Frequency: 8KHz-128KHz
- Working Voltage: 2 - 6S
- Continuous Current: 65A
- Peak Current: 120A
- Protocol: Dshot600/300/150,Oneshot,Multishot,PWM
- Telemetry Return: Yes
- Galvanometer: Yes
- BEC: No
- Mounting Hole Spacing: 30.5x30.5mm 4mm/M3
- Size: 45.5x42.5x6mm (LxWxH)
- Weight: 17g
Package Contents
- SEQURE Blueson A2 4IN1 ESC × 1
- 30AWG 40mm reverse double plug SH1.0-8P cable × 1
- 30AWG 60mm single plug SH1.0-8P cable × 1
- 12AWG 100mm power cable (black/red)×2
- XT60H-M black male connector×1
- 35V 680UF solid capacitor×1
- M3*8mm shock absorbing washer (black) × 5
- Mounting:
- 30.5x30.5
- Amps:
- 65
