RadioMaster TX15 MAX Radio Controller

PRE-ORDER NOTICE!
This is a pre-order. Shipping is expected around the end of August to early September. Please ONLY add the TX15 to your order. Additional items can be added once these are ready; please leave an order note and we will message you before it ships.

RadioMaster continues to raise the bar in open-source radio control. After years of collaboration with our open-source partners and user community, we're proud to introduce the TX15 MAX—our fastest, most feature-packed radio yet. Powered by the high-performance STM32 H7 chip, the TX15 MAX delivers buttery-smooth EdgeTX control, instant model switching, and ultra-fast script execution.

With 4GB of internal flash and MicroSD expansion, you'll have more than enough room for all your models, themes, sounds, and scripts—whether you're tuning for freestyle, racing, or long-range missions.

At the heart of the TX15 MAX is the Semtech LR1121 transceiver, offering dual-band 2.4GHz and 900MHz ExpressLRS (ELRS) support for exceptional range and ultra-low latency. A smart battery balancing circuit extends your flight time, while the sleek, foldable antenna keeps the radio portable without compromising signal strength.

Advanced features like the integrated gyro sensor with TiltX/TiltY let you pan cameras, toggle switches, or trigger telemetry alerts—all with a simple tilt of the radio. No hands? No problem.

The 3.5-inch IPS touchscreen delivers brilliant, daylight-visible visuals with 262K colors and 600 nits brightness. But what really sets the MAX apart is its hardware: AG02 CNC aluminum gimbals in your choice of anodized red, black, or gold, premium aluminum buttons, a carbon-fiber-look shell, and a tactile scroll wheel for easy navigation. Built-in RGB LEDs around the gimbals are fully customizable with LUA scripts—perfect for matching your style or flight mode at a glance.

You’ll also get USB-C fast charging, SIM card connectivity, high-speed firmware updates, active cooling, and top-tier memory access. Plus, we’ve included extra switch modules so you can swap the top shoulder buttons for momentary or latching switches—ideal if you prefer toggles over buttons.

Looking for a simpler option? Check out the TX15 Standard.

Features

• Blazing-Fast Performance: The STM32 H7 chip powers our fastest radio ever.
• Touchscreen Display: 3.5-inch, 480 x 320 IPS touchscreen with vivid colors and sharp detail.
• Precision Gimbals: the premium AG02 gimbals for enhanced smoothness.
• Built-in ExpressLRS: 2.4GHz / 900MHz ExpressLRS integration for reliable and long-range control.
• Smart Balance Battery Circuit: Maximizes battery efficiency and longevity for more flight time.
• Powerful, Cooling System: Low noise, high output fans and an aluminium heat sink keep your radio cool even on the hottest days.
• AG02 Gimbal: More than 20% reduced weight, with adjustable travel on both vertical and horizontal axis.
• Customizable RGB Gimbal Light- Ring: Integrated RGB LED lights around the gimbals allow customizable LUA-controlled lighting.
• Foldable Antenna: Compact and easy to store without compromising signal strength.
• Built-in Microphone: For future feature expansion.
• Built-in Gyro: Trigger switches, pan/tilt cameras, or telemetry callouts simply by tilting your radio.
• Memory: Integrated 4GB of onboard flash memory and external MicroSD card support.
• Interchangeable Shoulder Switches: Customize your controls to match your flying style.

Specifications

• Item: TX15 Max Radio Controller
• Size: 178*168*81mm
• Weight: 672g (without battery)
• Color: Red/ Black/ Gold
• Frequency: 2.400GHz OR Sub-G 900MHz
• Internal RF: ELRS 2.4GHz / Sub-G 900MHz
• Supported Protocols: Express-LRS
• Cooling Fan: Yes
• Transmitter Module: Built-in ELRS
• Built-in Flash Size: 4GB
• Built-in Microphone: Yes (Future expansion)
• Built-in Gyro: Yes (ICM-42607-C)
• MicroSD card* (Not included): 32GB/FAT32 (Inserting a MicroSD card will disable the onboard flash)
• Antenna Gain: 2dB (transmit power adjustable)
• Current: 875mA at max power output
• Voltage Range: 6.6 - 8.4V DC
• Radio Firmware: EdgeTX (Transmitter) (requires version 3.0.0 or later)
• Module Firmware: ExpressLRS
• Channels: Max 16 channels (Receiver dependent)
• Display: 3.5-inch IPS touchscreen (480 x 320 resolution)
• Battery: 7.4V 2-cell Lithium-Polymer / Two 3.7V 18650 Lithium-Ion cells / 21700 5000mAh Battery (batteries not included)
• Connectivity: USB-C
• Gimbals: AG02 CNC Hall sensor gimbals
• Gimbal Sticks: M4
• Upgrade Method: USB-C (UF2)
• Module Bay: JR-compatible module bay for additional modules

Dimensions

Downloads

• TX15 User Manual

Package Contents

• 1 * TX15 MAX Radio Controller
• 1 * Signature Carry Case
• 1 * Short 2-position Latching Shoulder Toggle Switch Assembly
• 1 * Short 2-position Momentary Shoulder Toggle Switch Assembly
• 1 * 18650 Battery Tray
• 1 * USB-C Cable
• 1 * Screen Protector
• 1 * 1.5mm Hex Wrench
• 4 * High Tension Gimbals Springs
• 2 * Gimbal Stick Set Screw
• 1 * Stickers Set
• 1 * User Manual
• 1 * Inventory Card
