Foxeer H7 MPU6000 FC 8S Dual BEC Barometer X8 Flight Controller
SKU:
FX-U1
Foxeer H7 MPU6000 FC 8S Dual BEC Barometer X8 Flight Controller
Specifications
- Model: Foxeer H7
- CPU: FOXEERH743
- Gyro: MPU6000
- Barometer: DPS310
- Power Supply: 4~8S Lipo
- BEC Output: 3.3V/0.5A;DC5V/2A;DC10V/2A
- OSD: BF OSD
- Black Box: 16M Flash Memory
- UART: 6 Sets+Rx8
- ESC: Telemetry RX8
- Buzzer: YES
- Connector: DJI/HDZero
- Smart Audio: YES
- LED 1 Set 2812 LED
- USB Type-C
- Servo S1,S2
- X8 Supported
- Firmware: BetaFlight: FOXEERH743
- Size: 37X37mm
- Mounting Hole: 30.5X30.5mm,Φ4mm
- Weight(g): 7.8g
- Working Temperature: -20℃ ~ +55℃
- Working Humidity: 20～95%
- Storage Temperature: -20℃ ~ +70℃
- Package Includes: 1*FC, 4*Rubbers Columns, 1*Cable
PACKAGE CONTENTS
- Width:
-
4.00
(cm)
- Height:
-
4.00
(cm)
- Depth:
-
0.50
(cm)
- Mounting:
- 30.5x30.5
- CPU:
- H7
