RadioMaster AG01 CNC Gimbal (Boxer/TX16S)

Designed and tested for over a year, the AG01 gimbals have been in development with our engineers and champion pro pilots such as MCK, Alex Campell, Noical, Veysi.FPV, AZFPV, Xiao Zheng, and Long XL to meet the demanding requirements of the world’s most competitive racing events.

The AG01 is fully CNC milled for ultimate precision with quad ball bearings for a smooth and precise feel. Featuring front-accessible tension and travel adjustment for easy fine-tuning. The AG01 will take your TX16s to the next level.

Features

• Designed specifically for the RadioMaster TX16S Radio
• Mode Switching Throttle Tension Adjustment
• CNC Aviation-Grade Aluminum
• Spring Tension Adjustment
• Non-Contact Hall Sensors
• Quad Precision Bearings
• Stick Travel Adjustment
• Ergonomic Stick Ends
• Adjustable Exterior

Specifications

• Type: AG01 Full CNC Hall Gimbal
• Full CNC Gimbal
• Product model: AG01
• Sensing type: Hall
• Working voltage: DC 3.3V
• Linearity: Real-time (No delay)
• Adjustable travel range: 38°—54°
• Adjustable mode: Yes
• Adjustable tension: Yes
• Quad bearing: Yes
• Temperature range: -20°c-85°c
• Size: 60*53*56mm
• Weight: 82g

Package Contents

• 2 x AG01 Full CNC Hall Gimbal (Centering / Throttle)
• 2 x TX16s Softer Tension Spring Set
• 2 x Hexagon socket screwdriver
• 2 x Manual
