DJI FPV Combo (Drone, Controller & V2 Goggles)

SKU:
CP.FP.00000001.01
$1,699.99

DJI FPV Combo (Drone, Controller & V2 Goggles)

***E-transfer payment method appreciated! :) :) :)


DJI FPV COMBO

Whether you’re a seasoned FPV pilot or a complete beginner, DJI FPV offers three intuitive flight modes that let anyone fly confidently from day one.



UNREAL FOOTAGE

The DJI FPV aircraft can record 4K/60fps video at up to 120 Mbps, capturing crisp details that make footage look as exhilarating as the flight.



ROCKSTEADY STABILIZATION

No matter how dynamic your maneuvers get, RockSteady EIS technology ensures your footage is ultra-smooth.



OCUSYNC 3.0

The DJI O3 (OcuSync 3.0) Transmission System was adapted to match the unique needs of DJI FPV. Enjoy crystal-clear real-time video transmission, even at distances of up to 10 km.



AUTO-SWITCHING FOR SEAMLESS SIGNAL

DJI FPV supports auto-switching between 2.4 and 5.8GHz frequencies and provides a video transmission bitrate of up to 50 Mbps, [8] significantly reducing stutter and compression artifacts. High-gain antennas on the aircraft include three transmitters and four receivers to enhance signal, resulting in a stable, reliable video feed.



EASILY REPLACEABLE PARTS

The gimbal camera, landing gear, and top shell of the DJI FPV aircraft are all modular and easily replaceable, making repairs more convenient. DJI Care Refresh is also available, offering coverage for a wide range of damage and giving you greater peace of mind as you fly.



Features

DJI FPV Drone

  • Onboard DVR, up to 4K@60FPS recording
  • Multiple flight modes
  • GPS equipped
  • Safety features such as return to home and obstacle avoidance
  • 795g with battery

DJI FPV Goggles V2

  • Minimum End-to-End Latency within 28ms
  • 810p 144 FPS Digital High Definition Display
  • Focus Mode allocates most image bitrate for the center of the image where you need it most.
  • 1800mAh Battery Included
  • Strong Anti-Interference
  • Maximum of 8 channels (5.8GHz)
  • 4KM safe transmission range
  • Live stream broadcast
  • Audience function lets another DJI FPV Goggle tune in to your signal
  • Betaflight PID Tuning, more integration in the works
  • Onboard Recording
  • Video Playback
  • Engineered to be lighter and more comfortable
  • Compatible with eyeglasses

Specifications

DJI FPV Drone

Camera

  • Sensor
    • 1/2.3” CMOS
    • Effective pixels: 12 million
  • Lens
    • FOV: 150°
    • 35mm Format Equivalent: 14.66 mm
    • Aperture: f/2.8
    • Focus Mode: Fixed Focus
    • Focus Range: 0.6 m to ∞
  • ISO: 100-12800
  • Shutter Speed: 1/50-1/8000 s
  • Still Photography Modes: Single shot
  • Max Image Size: 3840×2160
  • Photo Format: JPEG
  • Video Resolution
    • 4K: 3840×2160 at 50/60fps
    • FHD: 1920×1080 at 50/60/100/120fps
  • Video Formats: MP4/MOV (H.264/MPEG-4 AVC, H.265/HEVC)
  • Max Video Bitrate :120 Mbps
  • Color Profile: Standard, D-Cinelike
  • RockSteady EIS :Available
  • Distortion Correction: Available
  • Supported File Formats: exFAT (recommended), FAT32

Gimbal

  • Mechanical Range: Tilt: -65° to 70°
  • Controllable Range: Tilt: -50° to 58°
  • Stabilization: Single-axis (tilt), electronic roll axis
  • Max Control Speed: 60°/s
  • Angular Vibration Range: ±0.01° (N mode)
  • Electronic Roll Axis: Available (can stabilize footage when the aircraft is tilted at angles of up to 10°)

Aircraft

  • Takeoff Weight: Approx. 795 g
  • Dimensions
    • 255×312×127 mm (with propellers)
    • 178×232×127 mm (without propellers)
  • Diagonal Distance: 245 mm
  • Max Ascent Speed
    • M mode: No limit
    • S mode: 15 m/s
    • N mode: 8 m/s
  • Max Descent Speed
    • M mode: No limit
    • S mode: 10 m/s
    • N mode: 5 m/s
  • Max Speed
    • 140 kph; M mode: 39 m/s (27 m/s in Mainland China)
    • S mode: 27 m/s
    • N mode: 15 m/s
  • Max Acceleration: 0-100 kph: 2 s (in ideal conditions while flying in M mode)
  • Max Service Ceiling Above Sea Level: 6,000 m
  • Max Flight Time: Approx. 20 mins (measured while flying at 40 kph in windless conditions)
  • Max Hover Time: Approx. 16 mins (measured when flying in windless conditions)
  • Max Flight Distance: 16.8 km (measured while flying in windless conditions)
  • Max Wind Speed Resistance: 39-49 kph (25-31 mph)
  • Operating Temperature: -10° to 40° C (14° to 104° F)
  • Transmitter Power (EIRP)
    • 2.400-2.4835 GHz
    • FCC: ≤ 31.5dBm
    • CE: ≤ 20 dBm
    • SRRC: ≤ 20 dBm
    • MIC: ≤ 20 dBm
    • 5.725-5.850 Ghz
    • FCC: ≤ 31.5 dBm
    • CE: ≤ 14 dBm
    • SRRC: ≤ 25.5 dBm
  • Number of Antennas: Four
  • GNSS: GPS+GLONASS+GALILEO
  • Hovering Accuracy Range
    • Vertical:
      • ±0.1 m (with Vision Positioning)
      • ±0.5 m (with GPS positioning)
    • Horizontal:
      • ±0.3 m (with Vision Positioning)
      • ±1.5 m (with GPS positioning)
  • Supported SD Cards: microSD (up to 256 GB)
  • Internal Storage: N/A

Sensing System

  • Forward
    • Precision Measurement Range: 0.5-18 m
    • Obstacle Sensing: Available in N mode only
    • FOV: 56° (horizontal), 71° (vertical)
  • Downward (dual vision sensors + ToF)
    • ToF Effective Sensing Height: 10 m
    • Hovering Range: 0.5-15 m
    • Vision Sensor Hovering Range: 0.5-30 m
  • Downward Auxillary Light: Single LED
  • Operating Environment
    • Refers to non-reflective, discernible surfaces
    • Diffuse reflectivity >20% (e.g. walls, trees, people)
    • Adequate lighting conditions (lux >15 in normal indoor lighting conditions)

DJI FPV Remote Controller

  • Operating Frequency
    • 2.400-2.4835 GHz
    • 5.725-5.850 GHz
  • Transmitter Power (EIRP)
    • 2.400-2.4835 GHz
    • FCC: ≤ 28.5 dBm
    • CE: ≤ 20 dBm
    • SRRC: ≤ 20 dBm
    • MIC: ≤ 20 dBm
    • 5.725-5.850 GHz
    • FCC: ≤ 31.5 dBm
    • CE: ≤ 14 dBm
    • SRRC: ≤ 19 dBm
  • Max. Transmission Distance: 10 km (FCC), 6 km (CE), 6 km (SRRC), 6 km (MIC)
  • Gimbal Dimensions: 190×140×51 mm
  • Weight: 346 g
  • Battery Life: Approx. 9 hours
  • Charging Time: 2.5 hours

DJI FPV Goggles V2

  • Dimensions:
    • 202 × 126 × 110 mm (antennas included)
    • 184 × 122 × 110 mm (antennas excluded)
  • Weight: 420g (Headband and antennas included)
  • Screen Size: 2x2"
  • Screen Resolution (Single Screen): 1440 × 810
  • Screen Refresh Rate: 144 Hz
  • Communication Frequency: 2.400 - 2.4835 GHz*; 5.725-5.850 GHz *Only supports 5.8Ghz when used with DJI FPV Air Unit
  • Transmitter Power (EIRP) :
    • 2.400 - 2.4835 GHz FCC/MIC: ≤28.5 dBm; CE: ≤20 dBm; SRRC: ≤20 dBm; MIC: ≤20 dBm
    • 5.725-5.850 GHz FCC/MIC: ≤31.5 dBm; CE: ≤14 dBm; SRRC: ≤19 dBm
  • Live View Mode: Low Latency Mode (810p/120fps) High-Quality Mode (810p/60fps)
  • Video Format: MP4 (Video format: H.264)
  • Supported Video Play Format: MP4, MOV, MKV (Video format: H.264; Audio format: AAC-LC, AAC-HE, AC-3, MP3)
  • Operating Temperature: 32° to 104° F (0° to 40° C)
  • Power Input: 7.4-17.6 V
  • FOV: Adjustable from 30° to 54°. Adjustable image size from 50%-100%
  • Interpupillary Distance Range: 58 -70 mm
  • Supported Storage Card: microSD cards with capacities of up to 256GB

DJI FPV Goggle Battery

  • DJI FPV Goggles Battery Capacity: 1800mAh
  • Voltage: 9 V (Max.)
  • Type: LIPO 2s
  • Charging Temperature: 0°C to 45°C
  • Energy: 18 Wh
  • Max Charging Power 10 W
  • Battery Life: Approx. 110 minutes (measured in an environment of 25°C at maximum brightness level)

Intelligent Flight Battery

  • Battery Capacity: 2000 mAh
  • Voltage: 22.2 V
  • Max Charging Voltage: 25.2 V
  • Battery Type: LiPo 6S
  • Energy: 44.4 Wh@0.5C
  • Discharge Rate: Standard: 10C
  • Weight: 295 g
  • Charging Temperature: 5° to 40° C (41° to 104° F)
  • Max Charging Power: 90 W

Charger

  • Input: 100-240 V, 50/60 Hz, 1.8 A
  • Output:
    • Battery charging interface:
      • 25.2 V ± 0.1 V
      • 3.57 A ± 0.1 A (high current)
      • 1 A ± 0.2 A (low current)
    • USB Port: 5V/2A (×2)
  • Rated Power: 86 W

Package Contents

  • 1x DJI FPV Combo (Drone, Controller & V2 Goggles)
Width:
40.00 (cm)
Height:
32.00 (cm)
Depth:
30.00 (cm)
