Caddx Nebula Pro + Vista - Digital HD VTX Air Unit Kit for DJI

SKU:
NEBULA-PRO
$199.99

Out of stock

Out of Stock

Caddx Nebula Pro + Vista - Digital HD VTX Air Unit Kit for DJI

*White Version


Specifications

  •  Dimensions (Module): 30.45 x 29 x 13mm
  •  Weight: Vista kit(camera included):27g
  •  Antenna: 3.5g
  •  dimension Vista: 30*29*13mm
  •  Camera:19*19*20.3mm
  •  Coaxial cable:12cm
  •  Operating Frequency 5.725-5.850 GHz
  •  Transmitter Power (EIRP) FCC/SRRC/MIC: <30 dBm; CE: <14 dBm
  •  Min. Latency (end-to-end) Low latency mode (720p/120fps): 21-28ms / High quality mode (720p/60fps): 30-40ms
  •  Max transmission distance FCC/SRRC: 4km; CU: 0.7km.
  •  I/O Interface USB-C,IPX, 3-in-1 port
  •  Supported flight control system: F3. F4. F7
  •  Operating Temperature Range 0°C - 40°C(32°F - 104°F)
  •  Input Power 7.4 V - 26.4V
  •  Channels Up to 8 channels with 20MHz bandwidth are supported. Channel 8 is a public channel.



Package Contents

  • 1 x Nebula Pro + Vista Kit
Width:
15.00 (cm)
Height:
3.00 (cm)
Depth:
5.00 (cm)
mW:
700
